9.2

Control via the PLC inputs and outputs

9.2.1

PLC inputs

If the Modul100 shall be controlled via the PLC inputs and output, select one of the
control location "PLC", "All" or "Local and PLC" (refer to chapter or SB).
Caution
The electronic system of the Modul1000 may be damaged by too high input
voltages.
The maximum permissible input direct voltage is 30V.
The 14-pin Phönix-connector box is located at the back of the device and is marked
with PLC In / Audio. The pin assignment of the connector box is freely selectable
(Also refer to Interface Description).
Pin Assignment
24V fuse-protected with F3 on the interface board (0.8 A, maximum output
1
current, on this pin together with Pin 1 on connection PRESSURE GAUGE)
2 GND
3 Freely configurable PLC input
4 Freely configurable PLC input
5 Freely configurable PLC input
6 Freely configurable PLC input
7 Freely configurable PLC input
8 Freely configurable PLC input
9 Freely configurable PLC input
10 Freely configurable PLC input
11 PLC GND (reference potential)
12 free
13 AUDIO_OUT
14 GND (24 V)
The pins are numbered from the left to the right side.
Error or warning messages may occur when the connection cable is disconnected or
connected during operation.
Description of operation mode of the Digital In.
A signal between 0 V and 7 V is recognized to be LOW, a signal >13V is recognized
to be HIGH. The maximum signal level of direct voltage is 30V. All functions are also
selectable as inverted functions.
Signals at these inputs are only accepted if the location of control is set to
Notice:
PLC or Local and PLC.
e.g. START (default setting)
e.g. STOP (default setting)
e.g. ZERO (default setting)
e.g. CAL (default setting)
e.g. CAL INTERN(default setting)
e.g. CAL EXTERN (default setting)
e.g. CLEAR (default setting)
e.g. GAS BALLAST (default setting)
5V level, PWM-output
Technical Data
9-3
