6.9.6.6

Main menu

6-27
Operation
CAL Transient time
This menu is used to set how long it takes from the opening the test leak valve to the
measuring of the steady-state signal when it is automatically calibrated internally and
externally. This times depends on the volume which is on the inlet during calibration.
Maintenance intervals
Maintenance inter-
val rest device
Reset the mainte-
nance interval TMP
Maintenance
message for TMP
Maintenance Inter-
val Fan Filter
Maintenance
message Fan Filter
Switching mainte-
nance messages
of the overall device
on/off
Maintenance messages should be deactivated only if there is a separate
Notice:
maintenance schedule and the maintenance, authorizations, intervals etc.
described in chapter 7 were taken into consideration.
Warning
If the maintenance message is ignored and the contaminated filter is not replaced,
there will be the risk of overheating for the Modul1000.
Settings Load/Save Parameters
Save in "PARA SET 1"
Save in "PARA SET 2"
Save in "PARA SET 3"
Resets the maintenance interval of the overall device
(refer to chapter 7 Maintenance Works)
It resets the maintenance interval of the turbo-molecular
pump
(refer to chapter 7 Maintenance Works)
This menu item „maintenance message for TMP" serves for
resetting the maintenance messages, which appear
automatically after the maintenance interval has expired.
In the Maintenance Interval Fan Filter menu, the
maintenance interval can be defined in steps of 500 h. The
highest value is 4000 hours. If the percentage of dust in the
air at the measured site very high, the interval should be
short.
This menu item „Maintenance Message Fan Filter" serves
for resetting the maintenance messages, which appear
automatically after the maintenance interval has expired.
The maintenance messages can be switched on or off for
the overall device.
