Inficon Modul1000 Operating Manual page 118

No. Displayed Message
W64 Pre-amplifier signal is too high.
E68 TMP frequency too low!
Signal difference between test
W69
leak and air too small!
Supply voltage
W70
+/-15 V too low.
Supply voltage
W71
+/-15 V too high.
E73 Emission off (p2 too high)
Maximum of evacuation time of
W75
100 mbar was exceeded.
The maximum evacuation time
W76 until the measuring mode was
exceeded.
W77 Peak not in Range
Differences of signal between
W78 open and closed test leak is too
low.
10-6
Error Messages and Warnings
Description and possible solutions
In the most insensitive measurement range the pre-amplifier signal has exceeded
10 V for 10 s.
Strong helium contamination of the high-vacuum system.
The pre-amplifier is faulty.
High contamination in the mass spectrometer.
TMP frequency of nominal speed dropped in sniffer mode.
Sniffer not connected!
Sniffer line leaky.
Frequency converter is faulty. Replace TMH 071.
Signal difference between test leak and < 2 x 10E-14 A.
Incorrect operation during calibration
Test leak too low!
Test leak is empty.
DC/DC converters on the MSV board generate to low output voltages.
Fuse F3 on the MSV board is defective.
DC/DC transformer on MSV board is defective.
Jumpers for DC/DC transformer on the MSV board are incorrectly plugged.
DC/DC converters on the MSV board generate to high output voltages.
DC/DC transformer on MSV board is defective.
The emission is switched off when the pressure is p2 > 22 mbar
If the pressure decreases after the intake valve has been closed, the leak test
device goes back to the stand-by mode.
Air penetration during the measuring mode.
Polluted valves
The pressure limit of 10 mbar was not reached within the set evacuation time .
Test sample has got a GROSS leak.
The evacuation time is incorrectly adapted to the sample volume.
The pressure limit of 0.4 mbar was not reached within the set evacuation time .
Test sample has got a GROSS leak.
The evacuation time is incorrectly adapted to the sample volume.
The signal maximum could not be detected within the mass calibration range. The
signal maximum has shifted to mass range alignment limits.
Incorrect basic setting of the anode voltage. Perform a manual mass calibration
and reset the anode voltage via service menu .
Leak rate signal was unstable during the mass calibration. Calibrate again.
Wrong or incorrect test leak. Check internal test leak and repeat the calibration
with the external test leak.
Amplifier-voltage difference between the open and closed test leak is
14 A.
Internal test leak is defective.
The external test leak valve is defective or not closed.
2 x 10E-
