PLC Outputs

9-6
Technical Data
The 16-pin Phönix-connector box is located at the back of the device and is marked
with PLC Out. The pin assignment of the connector box is freely selectable.
Relay outputs (pin 3-12): Maximum load 60V DC / 25V AC / 1A ohmic load,
Notice:
for maximum 500,000 switching operations.
Semiconductor-relay outputs (pin 13, 14): maximum load 30 V, 1 A for frequent
switching operations.
For frequent switching operations (more than 500,000 within the planned operating
time), only the semiconductor-relay outputs should be used.
Pin Assignment
24V fuse-protected with F4 on the interface board
1
(1.6A, maximum output current, on this pin together with pin 1 on pin VALVES)
2 GND
Normally-open contact to pin
3
15
Normally-open contact to pin
4
15
Normally-open contact to pin
5
15
Normally-open contact to pin
6
15
Normally-open contact to pin
7
15
Normally-open contact to pin
8
15
Normally-open contact to pin
9
15
Normally-open contact to pin
10
15
Normally-open contact to pin
11
15
Normally-open contact to pin
12
15
Normally-open contact to pin
13
15
Normally-open contact to pin
14
15
15 „COM_DIGOUT" common reference potential for all outputs
16 Not used
All functions are also selectable as inverted functions. All relay outputs are open
when the device has been switched off.
OPEN:
If not triggered, the relay contact is open.
CLOSE:
If not triggered, the relay contact is closed.
e.g. TRIGGER1 (default setting)
e.g. TRIGGER2 (default setting)
e.g. TRIGGER3 (default setting)
e.g. ZERO ACTIVE (default setting)
e.g. EMISSION ON (default setting)
e.g. ERROR (default setting)
e.g. CAL ACTIVE (default setting)
e.g. CAL REQUEST (default setting)
e.g. OPEN (default setting)
e.g. OPEN (default setting)
e.g. OPEN (default setting)
e.g. OPEN (default setting)
