7.8 Replacing of parameter memory (I•STICK)
Required Tools
Required material
The customer's application parameters are also stored in I•STICK If a backup unit is
required, the application parameters can easily be transferred by connecting the
I•STICK to the backup unit.
• Allen key SW 8
• Screwdriver size 1
• I•STICK
Access to the I•STICK is only possible when the cover of the Modul1000 has been
removed. Follow the instructions in
Please observe the safety instructions in this chapter.
Notice:
• To replace the I•STICK, release the two screws with which the I•STICK is
screwed on the connector. See the
1
2
Fig. 7-7 I•STICK replacement
Item Description
1 I•STICK
After the screws have been released, pull the I•STICK out of the socket and insert
the I•STICK of the defect device.
The installation is performed in reverse order.
7.5.1 Opening of the Device.
Fig. 7-7 below.
Item Description
2 Fixing screws
Maintenance tasks
7-13
