SBC84620 AMD Geode GX3 All-in-One Capa Board User's Manual
1.1

Specifications

CPU
®
AMD LX800 (GX3) and optional LX700 processors
System Chipset
CS5536AD
CPU Frequency
LX800 500 MHz (optional LX700 433 MHz)
BIOS:
Phoenix-Award BIOS, Y2K compliant
4Mbit Flash, DMI, Plug and Play
PXE Ethernet Boot ROM
"Load Optimized Default" to backup customized Setting in
the BIOS flash chip to prevent from CMOS battery fail
System Memory:
One 200-Pin DDR SODIMM socket
Maximum DDR of up to 1GB DDR333
Onboard IDE:
One PATA-100 with 44-pin 2.0 pitch box-header
PATA-100 as PIO Mode 0-4, DMA Mode 0-2 and Ultra
DMA/33/66/100
Compact Flash Socket:
One Compact Flash Type II Socket
Onboard Multi I/O:
Three RS-232 and one RS-232/422/485
PC/104
NOTE The PCI/104 slot supports I/O mode module only.
USB Interface
Four USB ports with fuse protection and comply with USB
Sepc. Rev. 2.0
2
Introduction
