SBC84620 AMD Geode GX3 All-in-One Capa Board User's Manual
ECP Mode Use DMA
Select a DMA channel for the parallel port for use during ECP
mode.
Onboard Serial Port 3/Port 4
Select an address for the third and fourth serial ports. The options
available are "3F8", "2E8", "3E8", "2F8" and "Disabled".
Serial Port 3/Port 4 Use IRQ
Select corresponding interrupt for the third and fourth serial ports.
The options available are "IRQ10" and "IRQ11".
IDE Primary Master/Slave PIO
The four IDE PIO (Programmed Input/Output) fields let you set a
PIO mode (0-4) for each of the four IDE devices that the onboard
IDE interface supports. Modes 0 through 4 provide successively
increased performance. In Auto mode, the system automatically
determines the best mode for each device. The options available
are "Auto", "Mode 0", "Mode 1", "Mode 2", "Mode 3" and "Mode 4".
IDE Primary Master/Slave UDMA
Ultra DMA 66/100 implementation is possible only if your IDE hard
drive supports it and the operating environment includes a DMA
driver (Windows 95 OSR2 or a third-party IDE bus master driver). If
your hard drive and your system software support Ultra DMA
33/66/100, select Auto to enable BIOS support. The options
available are "Auto", "Mode 0", "Mode 1" and "Mode 2".
IDE HDD Block Mode
This field allows your hard disk controller to use the fast block
mode to transfer data to and from your hard disk drive.
Onboard Audio
Select Enabled if your system contains a Audio controller and you
want to use it.
Onboard LAN Boot ROM
This item allows you to decide to boot from whether LAN1 or LAN2.
The options available are "LAN1", "LAN2" and "Disabled".
Award BIOS Utility
50
