SBC84620 AMD Geode GX3 All-in-One Capa Board User's Manual
IDE Primary Master / Primary Slave
The categories identify the types of one channel that have been
installed in the computer. There are 45 predefined types and 2
users definable types are for Enhanced IDE BIOS. Type 1 to Type
45 is predefined. Type User is user-definable.
Press <PgUp>/<+> or <PgDn>/<−> to select a numbered hard disk
type or type the number and press <Enter>. Note that the
specifications of your drive must match with the drive table. The
hard disk will not work properly if you enter improper information
within this category. If your hard disk drive type does not match or
is not listed, you can use Type User to define your own drive type
manually.
If you select Type User, related information is asked to be entered
to the following items. Enter the information directly from the
keyboard and press <Enter>. This information should be provided
in the documentation from your hard disk vendor or the system
manufacturer.
If the controller of HDD interface is ESDI, select "Type 1".
If the controller of HDD interface is SCSI, select "None".
If the controller of HDD interface is CD-ROM, select "None".
number of cylinders LANDZONE
CYLS.
HEADS number of heads
PRECOMP write precom
If there is no hard disk drive installed, select NONE and press
<Enter>.
Halt On
This field determines whether the system will halt if an error is
detected during power up.
No errors
All errors
All, But
Keyboard
All, But
Diskette
Award BIOS Utility
SECTORS
MODE
The system boot will halt on any error detected.
(default)
Whenever the BIOS detect a non-fatal error, the
system will stop and you will be prompted.
The system boot will not stop for a keyboard error; it
will stop for all other errors.
The system boot will not stop for a disk error; it will
stop for all other errors.
landing zone
number of sectors
HDD access mode
43
