SBC84620 AMD
Geode GX3 All-in-One Capa Board User's Manual
2.3.1
Audio Output Select Jumper (JP1)
Description
Audio Output
Selection
2.3.2
LCD Voltage Select Jumper (JP2)
Description
LCD Voltage
Select
10
Function
Line Out
(Default)
Speak Out
Function
3.3V (Default)
5V
Jumper Setting
JP1
JP1
Jumper Setting
JP2
JP2
