option to XOR with upper address bits.
The default setting is "LOI".
XOR BA0/ BA1/MB0
Enables XORing of component bank select BA0/BA1/MB0 with
upper GLIU address bit. The default value is "Disabled".
XOR Bit Select
Select which upper GLIU address bit to XOR with MB0, BA1 or
BA0. Only applies to LOI mode. The choice: 18, 19, 20, 21. The
default value is "18".
Video Memory Size
The options available are [8M] [16M] [32M] [64M] [128M] [254M].
Output Display
This allows you to choose output for your system display.
Configuration options: [CRT] [Flat Panel] [Panel +CRT]. The default
value is "Panel +CRT".
Flat Panel Configuration
Press Enter to set the following items.
Resolution
Select the resolution for LVDS panel.
Data Bus Type
Select the Data Bus Type for LVDS panel.
Refresh Rate
Select the refresh rate for LVDS panel.
HSYNC Polarity
The choice: HI, LOW.
VSYNC Polarity Active
The choice: HI, LOW.
SHFCLK Active Period
Select the shift clock (SHFCLK) to be either free running, or active
only during the display period. Some TFT panels recommend
keeping the shift clock running during the retrace time.
LP Active Period
Select the polarity of the LDE/MOD pin. This can be used for
panels that require an active low timing LDE interface signal.
