SBC84620 AMD
Geode GX3 All-in-One Capa Board User's Manual
Pin
Signal
22
Data 1
23
Data 2
24
IOCS16#
25
CD2#
CN17
2.4.17 USB Connectors (USB1, USB2)
The board supports four Universal Serial Bus (USB) connectors
compliant with USB 2.0 (480 Mbps) that can be adapted to any USB
peripherals, such as monitor, keyboard, and mouse.
2.4.17.1 USB Port Connector (USB2)
The Universal Serial Bus (USB) port connector on the board is for the
installation of peripherals supporting the USB interface. USB2 consists
of two 4-pin standard USB ports.
USB0 and USB1
Pin
1, 5
2, 6
3, 7
4, 8
USB GND
Jumpers and Connectors
Pin
47
Data 8
48
Data 9
49
Data 10
50
GND
Signal
USB Vcc
USB -
USB +
Signal
USB2
33
