eBOX626A Series user's Manual
Reliable and Stable Design
The embedded system supports Intel
high flexibility and multi-functional design that makes it the best solution for smart factory, AIOT,
Edge Computing, Factory automation applications.
Flexible Connectivity
The eBOX626A comes with rich I/O interfaces including one RS-232/422/485 ports, two RS-
232, four USB 3.1 ports, two USB 2.0 ports, one GbE port, one 2.5GbE port, one
HDMI(lockable), one VGA, one mPCIe expansion slot and one M.2 key E.
Embedded O.S. Supported
The eBOX626A supports Windows
Various Storage Supported
In terms of storage, the eBOX626A supports one 2.5" SATA storage drive bay and one mSATA
devices.

1.2 System Specifications

1.2.1 CPU

⚫ CPU
◼ Intel® Celeron
⚫
BIOS
◼ American Megatrends Inc. UEFI (Unified Extensible Firmware Interface) BIOS.
⚫ System Memory
◼ 1 x 260-pin DDR4-3200 SO-DIMM, up to 32GB

1.2.2 I/O System

⚫ Display
◼ 1 x VGA (Resolution: 1920x1080@60Hz)
◼ 1 x HDMI 1.4b (Resolution: 3840x2160@30Hz)
⚫ Ethernet
◼ 1 x 10/100/1000/2500 Mbps Ethernet supports Wake-on-LAN, UEFI PXE with
i226-LM
◼
1 x 10/100/1000 Mbps Ethernet supports Wake-on-LAN, UEFI PXE with Intel
i210-AT
⚫ USB Ports
◼ 4 x USB 3.1 Gen2
◼ 2 x USB 2.0
⚫
Serial Ports
◼
2 x RS-232 (COM 2, COM3)
◼ 1 x RS-232/422/485 (COM1)
⚫ Digital IO
◼ 1 x optional 8-CH DIO by MOQ50 (default : 4in/4out)
*must remove COM 3 to add 8-CH DIO*
2
®
Celeron
®
10, Windows
®
J6412 (Elkhart Lake), up to 10W
Processor J6412 (Elkhart Lake), along with
®
®
10 IoT and various Linux versions.
Introduction
