Real Time Clock
Integrated CS5536AD
Watchdog Timer:
1~255 seconds; up to 255 levels
Graphics/Streaming:
Integrate LX800
Unified Memory Architecture shares system memory up to
254MB
LCD Interface -- Supports up to 24-bit TFT LCD (TTL
signal)
CRT: 1600 x 1200 x 32 bpp
LCD: 1600 x 1200 x 32 bpp
Ethernet:
Realtek RTL8139DL PCI Bus 10/100M Base-T
Wake On LAN (via ATX power supply)
Equipped with RJ-45 interface
Audio:
Realtek ALC202A AC'97 codec audio
Amplify for speaker-out with 1W for each channel
MIC-in, Line-in, Line-out/Speaker-out (jumper selectable)
Power Management
ACPI (Advanced Configuration and Power Interface) / APM
Form Factor:
3.5" hard disk drive form factor
NOTE All specifications and images are subject to change
without notice.
