2.3.6 COM1 Mode Select Jumper (JP6)
Description
COM1 (JP6)
Jumpers and Connectors
Function
*Pin 1=DCD
(Default)
*Pin 1=5V
*Pin 9=RI
*Pin 9=+12V
Jumper Setting
JP6
JP6
JP6
JP6
