SBC84620 AMD
Geode GX3 All-in-One Capa Board User's Manual
Pin
67
SERR#
69
GND
71
PERR#
73
C/BE1#
75
AD14
77
GND
79
AD12
81
AD10
83
GND
85
AD08
87
AD07
89
3.3V
91
AD05
93
RESERVED
95
5V
97
5V
99
AD01
101
GND
103
RESERVED
105
RESERVED
107
RESERVED
109
RESERVED
111
RESERVED
113
RESERVED
115
RESERVED
117
RESERVED
119
RESERVED
121
RESERVED
123
RESERVED
2.4.8
ATX Power Connector (CN8)
Steady and sufficient power can be supplied to all components on the
board by connecting the power connector. Please make sure all
components and devices are properly installed before connecting the
power connector. Align the power connector with its proper location on
the board, and connect it tightly.
24
Signal
Pin
68
STOP#
70
3.3V
72
DEVSEL#
74
GND
76
AD15
78
AD13
80
AD11
82
GND
84
AD09
86
C/BE0#
88
3.3V
90
AD06
92
AD04
94
AD02
96
AD00
98
RESERVED
100
RESERVED
102
GND
104
RESERVED
106
RESERVED
108
RESERVED
110
RESERVED
112
RESERVED
114
GND
116
RESERVED
118
RESERVED
120
RESERVED
122
RESERVED
124
RESERVED
Signal
Jumpers and Connectors
