SBC84620 AMD
Geode GX3 All-in-One Capa Board User's Manual
2.3.5
COM1 Mode Select Jumpers for RS-232/422/485
(JP5, JP7, JP10)
Description Function
COM1
RS-232
(Default)
RS-422
RS-485
12
Jumper Setting
JP10
JP5
JP10
JP5
JP10
JP5
Jumpers and Connectors
JP7
JP7
JP7
