SBC84620 AMD
Geode GX3 All-in-One Capa Board User's Manual
2.3.7 COM2 Mode Select Jumper (JP8)
Description
COM2 (JP8)
14
Function
*Pin 1=DCD
(Default)
*Pin 1=5V
*Pin 9=RI
*Pin 9=+12V
Jumper Setting
JP8
JP8
JP8
JP8
Jumpers and Connectors
