SBC84620 AMD
Geode GX3 All-in-One Capa Board User's Manual
3.1
Microprocessors
The SBC84620 Series supports LX700/LX800.Systems based on
these CPUs can be operated under Windows XP and Linux
environments. The system performance depends on the
microprocessor installed onboard. Make sure all settings are correct for
the installed microprocessor to prevent any damage to the CPU.
3.2
BIOS
System BIOS used on the SBC84620 Series is Phoenix-Award Plug
and Play BIOS. The SBC84620 Series contains a single 4Mbit Flash.
3.3
System Memory
The SBC84620 Series industrial CPU card supports one 200-pin DDR
SODIMM socket for a maximum memory of 1GB DDR SDRAMs. The
memory module can come in sizes of 64MB, 128MB, 256MB, 512MB
and 1GB.
Hardware Description
C h a p t e r 3
Hardware Description
35
