SBC84620 AMD
Geode GX3 All-in-One Capa Board User's Manual
2.3.10 COM3 Mode Select Jumper (JP12)
Description
COM3 (JP12)
16
Function
*Pin 1=DCD
(Default)
*Pin 1=5V
*Pin 9=RI
*Pin 9=+12V
Jumper Setting
JP12
JP12
JP12
JP12
Jumpers and Connectors
