SBC84620 AMD Geode GX3 All-in-One Capa Board User's Manual
2.4.7

Mini PCI Connector (CN7)

Pin
1 TIP
KEY
3 LAN_RD+
5 LAN_RD-
7 RJ45 termination
9 RJ45 termination
11 LAN_LED1+
13 LAN_LED1-
15 CHGND
17 INTB#
19 3.3V
21 RESERVED
23 GND
25 CLK
27 GND
29 REQ#
31 3.3V
33 AD31
35 AD29
37 GND
39 AD27
41 AD25
43 RESERVED
45 C/BE3#
47 AD23
49 GND
51 AD21
53 AD19
55 GND
57 AD17
59 C/BE2#
61 IRDY#
63 3.3V
65 CLKRUN#
Jumpers and Connectors
Signal Pin
2 RING
KEY
4 LAN_TD+
6 LAN_TD-
8 RJ45 termination
10 RJ45 termination
12 LAN_LED2+
14 LAN_LED2-
16 RESERVED
18 5V
20 INTA#
22 RESERVED
24 3.3VAUX
26 RST#
28 3.3V
30 GNT#
32 GND
34 PME#
36 RESERVED
38 AD30
40 3.3V
42 AD28
44 AD26
46 AD24
48 IDSEL
50 GND
52 AD22
54 AD20
56 PAR
58 AD18
60 AD16
62 GND
64 FRAME#
66 TRDY#
Signal
23
