6 How to Programme the Low Harmonic Drive

6.4.4 Special Functions 14-**

Par. Parameter description
No. #
14-2* Trip Reset
14-20 Reset Mode
14-21 Automatic Restart Time
14-22 Operation Mode
14-23 Typecode Setting
14-28 Production Settings
14-29 Service Code
14-5* Environment
14-50 RFI Filter
14-53 Fan Monitor
14-54 Bus Partner

6.4.5 FC Information 15-**

6
Par. Parameter description
No. #
15-0* Operating Data
15-00 Operating Hours
15-01 Running Hours
15-03 Power Up's
15-04 Over Temp's
15-05 Over Volt's
15-07 Reset Running Hours Counter
15-1* Data Log Settings
15-10 Logging Source
15-11 Logging Interval
15-12 Trigger Event
15-13 Logging Mode
15-14 Samples Before Trigger
15-2* Historic Log
15-20 Historic Log: Event
15-21 Historic Log: Value
15-22 Historic Log: Time
15-3* Fault Log
15-30 Fault Log: Error Code
15-31 Fault Log: Value
15-32 Fault Log: Time
15-4* Unit Identification
15-40 FC Type
15-41 Power Section
15-42 Voltage
15-43 Software Version
15-44 Ordered Typecode String
15-45 Actual Typecode String
15-46 Unit Ordering No
15-47 Power Card Ordering No
15-48 LCP Id No
15-49 SW ID Control Card
15-50 SW ID Power Card
15-51 Unit Serial Number
15-53 Power Card Serial Number
15-6* Option Ident
15-60 Option Mounted
15-61 Option SW Version
15-62 Option Ordering No
15-63 Option Serial No
15-70 Option in Slot A
15-71 Slot A Option SW Version
15-72 Option in Slot B
15-73 Slot B Option SW Version
15-74 Option in Slot C0
15-75 Slot C0 Option SW Version
15-76 Option in Slot C1
15-77 Slot C1 Option SW Version
15-9* Parameter Info
15-92 Defined Parameters
15-93 Modified Parameters
15-98 Unit Identification
15-99 Parameter Metadata
148
Default value 4-set-up
[0] Manual reset All set-ups
10 s All set-ups
[0] Normal operation All set-ups
null 2 set-ups
[0] No action All set-ups
0 N/A All set-ups
[1] On 1 set-up
[1] Warning All set-ups
1 N/A 2 set-ups
Default value 4-set-up
0 h All set-ups
0 h All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
[0] Do not reset All set-ups
0 2 set-ups
ExpressionLimit 2 set-ups
[0] False 1 set-up
[0] Log always 2 set-ups
50 N/A 2 set-ups
0 N/A All set-ups
0 N/A All set-ups
0 ms All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 s All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
®
