LCD Status Options

The Status Display of the LCD is divided into four quadrants, the top-left, top-right, bottom-left, and bottom-
right. Each of these four quadrants can be customized to show a different piece of information about the
status of the device or show.
The default Status Display for CueServer 2 has the following quadrant layout:
Device Name
Show Name
The following table shows the available options and how they appear on the LCD display:
Status Type
Device Name
Show Name
Show Directory
IP Address
Timecode
IO Status
CPU Load
Long Date + 12-Hour Time
Short Date + 12-Hour Time
Long Date + 24-Hour Time
Short Date + 24-Hour Time
Long Date
Long Date + 12-Hour Time
IP Address
Example
CueServer 2
My First Show
/shows/My First Show/
IP: 10.0.1.234
TC: 00:00:00:00
[C:--*--*--][O:-----**-]
CPU: 7%
Feb 15, 2017 10:34:56 PM
2/15/17 10:34:56 PM
Feb 15, 2017 22:34:56
2/15/17 22:34:56
Feb 15, 2017
CueServer 2 User's Manual - 18.5.18
Description
The assigned name of the device.
The name of the active show.
The file system directory of the active show.
The IP Address of the device. If the device is
configured with multiple network LANs, the
display will alternate between both networks' IP
Addresses. If the Ethernet jack is unplugged, a
∅
symbol will appear in front of the address.
The current timecode within the system.
The current status of the built-in contact
closures and digital outputs. A
indicates that a contact is closed or an output is
active.
The current 5-minute average CPU load
percentage.
The long date and 12-hour time combined.
The short date and 12-hour time combined.
The long date and 24-hour time combined.
The short date and 24-hour time combined.
The long date.
symbol
*
