Interactive Technologies, Inc.
CueScript Protocol
CueScript Protocol is a method of sending CueScript commands to a CueServer over Ethernet.
CueServer listens for incoming UDP packets on port 52737 that contain a valid CueScript command string.
CueScript packets may be sent to CueServer by:
• Unicast to the CueServer's IP Address
• Multicast to the CueServer group address 239.255.204.2
The payload of the packet can be any valid CueScript command, such as:
• Cue 1 Go
• Q1G
• Macro 7
• M7
• Channel 1>10 At FL
• C1>10AFL
• Button 1 On; Wait 3.5; Button 1 Off
• If ('x' = 1) Then Playback 7 Clear
CueServer 2 User's Manual - 18.5.18
Page 81 of 429
