The clock backup battery has failed.
BAT
DMX Transceiver Loopback Test
DMX
OK
While the Self-Test is running, a DMX output test signal is generated by DMX Ports B & D (on the CS-900)
and DMX 1/2 Outputs (on the CS-940). A loopback to a corresponding input port is used so the Self-Test
function can verify that the data sent out of the output port is what is received by the input port. The
following table shows which output port should be looped with which input port.
CS-900 From (Output) To (Input)
Loopback 1 Port B
Loopback 2 Port D
CS-940 From (Output) To (Input)
Loopback 1 DMX 1 Out
Loopback 2 DMX 2 Out
The section of the display marked DMX shows the result of testing the DMX Input/Output circuitry. The
following table shows the possible values that are shown for this portion of the test:
DMX Meaning
All tests have passed.
OK
DMX Loopback 1 have errors.
1
2 DMX Loopback 2 have errors.
Both DMX Loopbacks have errors.
1+2
Use the RIGHT and LEFT navigation buttons to display either the DMX 1 or DMX 2 pages on the LCD to
view additional details about the DMX loopback tests.
The extra LCD pages that show detailed DMX loopback information appear similar to the following:
Port A
Port C
DMX 1 In
DMX 2 In
