Interactive Technologies CueServer 2 User Manual page 60

Interactive Technologies, Inc.
Source Menu
This menu has several options to specify the source of the DMX channel values that will be recorded into
the cue:
• DMX Input – The DMX channel values being input into the CueServer will be recorded. None of the
values in the playbacks or being output will be recorded.
• Playback n – The DMX channel values in Playback n will be recorded. Neither the DMX input or
output will be recorded.
• DMX Output – The DMX channel values being output from the CueServer will be recorded. This is the
default option.
Capturing Channel Values
Once the appropriate options have been selected, click on the Capture button to record the current DMX
values into the cue. The Capture window will close and the cue will be updated to show the newly captured
channels.
CueServer 2 User's Manual - 18.5.18
Page 58 of 429
