2.macro
3.macro
presets
Conference
0.zone
1.preset
2.preset
3.preset
Lobby
0.zone
1.preset
2.preset
rules
1.rule
2.rule
3.rule
show.cfg
stations
0
1.button
2.button
3.button
1.contact
2.contact
3.contact
1.output
2.output
The presets directory contains zone directories.
Each zone includes a 0.zone zone configuration file.
Within each zone, Preset file names use the same number as the preset. Preset
files end with the
.preset
Each additional zone is its own directory in the root directory. Zone names are
limited to 15 characters any may not contain spaces. Each zone directory also
contains a 0.zone configuration file and its own set of Preset resources.
The rules directory contains Rule resources. Rule file names are based on the
resource ID followed by the
This is the main show configuration file. It is always included in the root level off the
show directory. The show.cfg file contains settings for DMX patching, physical
location, LCD display, playbacks, global show preferences and more.
See show.cfg for details on this file format.
The stations directory contains sub-directories for each station. Station directories
are named with the ID number of the station. Station IDs always start at 0.
Individual resources for Buttons, Contacts, Outputs, and Serial Ports are included in
each station directory. The ID numbers for each resource and number of resources
for each type is dictated by the type and configuration of station. These files end with
the .button, .contact, .output, and
Each station directory includes a station.cfg file that defines the station properties.
A station with ID is always present and represents the "built-in" station that
0
corresponds to the front-panel buttons and included contact closures, outputs and
serial ports.
extension. Valid preset numbers range from
extension.
.rule
extensions.
.port
CueServer 2 User's Manual - 18.5.18
to 999.
1
