LCD Properties [lcd]

This request sets various LCD Display properties.
URL:
/set.cgi?dst=lcd&<optional-parameters>
Optional Parameters:
•
backlight=<0..255>
◦ This parameter (if present) sets the LCD Display's backlight brightness.
◦ Valid range is from
•
field=<1..4>&id=<0..16>
◦ This parameter group (if present) sets one of the four quadrants of the LCD Display to one of
the built-in display functions.
◦ Valid fields are from
◦ Valid display function ID is from
LCD Field Description
Top-Left
1
2 Top-Right
Bottom-Left
3
Bottom-Right
4
LCD Function Description
Blank
0
Device Name
1
2 Long Date + 12-Hour Time
Short Date + 12-Hour Time
3
4 Long Date + 24-Hour Time
Short Date + 24-Hour Time
5
(optional)
to 255.
0
(optional)
to (see below).
1 4
to (see below).
0 16
