DMX Ports

In addition to being able to transmit and receive DMX-over-Ethernet, CueServer also has built-in DMX ports
for hard-wired DMX connections to fixtures, dimmers, consoles and virtually any other DMX compatible
devices.
The rack-mounted CS-900 has four replaceable DMX module slots, and the miniature CS-920 has two
replaceable DMX module slots, each of which can accept any of seven available DMX modules for input or
output of DMX. The surface-mounted CS-940 has two DMX input ports and two DMX output ports that are
available on the unit's pluggable terminal block strips.
Specifications
CS-900
DMX Ports 4
Bi-Directional
4
Ports
Fixed Input Ports –
Fixed Output Ports –
Replacable DMX
Yes
Modules
Indicators
Description
Port Disabled
CS-900 or CS-920
Off
CS-920
2
2
–
–
Yes
CS-940
Off
CueServer 2 User's Manual - 18.5.18
CS-940
4
–
2
2
No
