Interactive Technologies CueServer 2 User Manual page 282

Interactive Technologies, Inc.
Set debug.udp 1
Set debug.cuescript 0
The example above enables UDP event logging and disables CueScript event logging.
*
Please note that all debugging functions are reset to "off" when a CueServer is power-cycled. Each desired
function must be re-enabled each time a CueServer is rebooted. Also, it is not recommended to leave a
debug log function enabled indefinitely, as some of these functions can result in the system log overflowing.
LCD Display
Sets the backlight brightness and various string fields for the LCD display.
lcd.backlight
lcd.top
lcd.bottom
lcd.topLeft
lcd.topRight
lcd.bottomLeft
lcd.bottomRight
Example:
Set lcd.backlight 25
Set lcd.top "Hello World"
Set lcd.bottom ""
The example above first sets the LCD Backlight brightness to 25%, then writes a temporary string to the top
line that says
Hello
Panel
Changes properties of the front-panel of the device.
panel.brightness
Sets the brightness of the LCD Backlight. Brightness values range from
Sets a temporary overlay string that replaces the top or bottom lines, or quadrant of the
display. Set this value to an empty string ("") to remove the temporary overlay.
World, then removes any temporary string from the bottom line.
Sets the overall brightness of the front-panel function button indicators and the
navigation switch backlight. Brightness values range from
CueServer 2 User's Manual - 18.5.18
to 100.
0
to 100.
0
Page 280 of 429
