ISD Safety Concept

8.10 Application Example

Illustration 8.2 shows an example of an installation for 2 lines that can be put in Safe Torque Off mode by separate safety
circuits for each line.
The safety circuits may be remote from each other and are not supplied from the ISD 510 servo system.
The 2 lines in the example are controlled separately. If the Safe Torque Off function is triggered on line 1, line 2 remains in
normal operation and the servo drives on this line are not affected. There may still be a hazard from the servo drives on
line 2.
Select the safety switch devices in accordance with the requirements of the application.
8
8
14
1a/1b
ISD 510 servo drive on line 1
2a/2b
ISD 510 servo drive on line 2
3
Servo Access Box (SAB)
4
Safety device on line 1
5
Line 1 emergency stop button
6
Line 1 safety device contacts
Illustration 8.2 Application Example: Safe Torque Off Function with 2 Lines
72
®
VLT
Integrated Servo Drive ISD
+24 V DC
–24 V DC
4
8
7
Danfoss A/S © 12/2015 All rights reserved.
®
510 System
5
3
10
6
11
9
7
Safety device on line 2
8
Line 2 emergency stop button
9
Line 2 safety device contacts
10
Line 1 hybrid cable
11
Line 2 hybrid cable
12
24 V DC supply
11
X1
1a
X2
13
X1
1b
X2
12
X1
2a
X2
13
X1
2b
X2
MG75K102
