Browser Server
About Netmasks
Revision A
Software Configuration: Monitor Service Menu
When Change Address... is selected:
an IP Address window and numeric keypad appear,
the current IP Addresses and netmasks display if they have been
entered,
the numeric keypad allows you to enter an address or netmask,
you can select OK to exit and store,
you can select Cancel to exit without saving, and
if OK is selected, a confirmation box appears so you can confirm any
change.
The following network addresses are invalid:
First octet of network address >239
1.0.0.0
1.1.0.0
1.1.1.0
0.1.0.0
0.0.1.0
1.1.1.0
127.0.0.1 (loopback address)
Addresses currently in use on the network
The Browser Server IP address must be a legal address on the Unity
Network IX network. The example below shows an acceptable and an
unacceptable address.
Acceptable
IX Network 151.1.2.3
Browser Server 151.1.2.2
Netmask 255.255.255.0
The variable netmask capability of the Solar 9500 allows for an advanced
network with intelligent routers. Typically for the Unity Network MC
network the netmask should be 255.0.0.0. For the Unity Network IX
network the netmask should be set to match the rules for subnet
segments as defined by the institution's network topology.
Solar 9500 Information Monitor
2001085-061
Not Acceptable
151.1.2.3
151.1.3.3
255.255.255.0
4-19
