Theory of Operation: Subassemblies
Audio signals are routed from the NLX motherboard through an audio
amplifier on the Riser Interface board to a speaker connector on the
Riser Interface board.
To All Logic
CLOCKS
PCI
3 PCI
Interface
Board
Slots
ISA Bus
Audio
Amp
Solar 9500 Information Monitor
2001085-061
PLX9080
Interface
Controller
Config
i82596CA
Prom
Network
Controller
Local Bus
Controller
FPGA
ISA Bus
Controller
FPGA
Power
Supply
Monitor
Speaker
Connector
i82596CA
Network
Controller
SRAM
256K
bytes
POWER
Connector
Revision A
