Specifications; Power-Dependent Specifications - Danfoss VLT FC 102 Installation Manual

Specifications

7 Specifications

7.1 Power-dependent Specifications

7.1.1 VLT ®
HVAC Drive FC 102
Power range
Drive modules
Rectifier configuration
High/normal load
Output current [A]
Continuous (at 380–440 V)
Intermittent (60 s overload) at 400 V
Continuous (at 460/500 V)
Intermittent (60 s overload) at 460/500 V
Input current [A]
Continuous (at 400 V)
Continuous (at 460/500 V)
Power losses [W]
Drive modules at 400 V
Drive modules at 460 V
AC bus bars at 400 V
AC bus bars at 460 V
DC bus bars during regeneration
2
Maximum cable size [mm (mcm)]
Mains
Motor
Brake
Regeneration terminals 1)
Maximum external mains fuses
6-pulse configuration
12-pulse configuration
Table 7.1 FC 102, 380–480 V AC Mains Supply (2-Drive System)
1) If Danfoss bus bar kit is used.
MG37K302
Installation Guide
N315 N355
2 2
12-pulse
NO NO
588 658
647 724
535 590
588 649
567 647
516 580
5825 6110
4998 5964
550 555
548 551
93 95
4x120 (250)
4x120 (250)
4x70 (2/0)
4x120 (250)
– –
700 A, 600 V
