Specifications
Power range
Drive modules
Rectifier configuration
High/normal load
Output current [A]
Continuous (at 380–440 V)
Intermittent (60 s overload) at 400 V
Continuous (at 460/500 V)
Intermittent (60 s overload) at 460/500 V
Input current [A]
Continuous (at 400 V)
Continuous (at 460/500 V)
Power losses [W]
Drive modules at 400 V
Drive modules at 460 V
AC bus bars at 400 V
AC bus bars at 460 V
7 7
DC bus bars during regeneration
Maximum cable size [mm
Mains
Motor
Brake
Regeneration terminals
Maximum external mains fuses
6-pulse configuration
12-pulse configuration
Table 7.2 FC 102, 380–480 V AC Mains Supply (4-Drive System)
1) If Danfoss bus bar kit is used.
46
®
VLT Parallel Drive Modules
2
(mcm)]
1)
Danfoss A/S © 08/2017 All rights reserved.
N560 N630
4 4
6-pulse/12-pulse
NO NO
990 1120
1089 1232
890 1050
979 1155
964 1090
867 1022
8810 10199
7628 9324
665 680
656 671
218 232
4x185 (350)
4x185 (350)
8x70 (2/0)
6x120 (250) 8x120 (250)
600 V, 600 V, 2000 A
1600 A
600 V, 700 A 600 V, 900 A
N710 N800 N1M0
4 4 4
NO NO NO
1260 1460 1720
1386 1606 1892
1160 1380 1530
1276 1518 1683
1227 1422 1675
1129 1344 1490
11632 13253 16463
10375 12391 13958
695 722 762
683 710 732
250 276 318
8x120 (250)
8x120 (250)
8x95 (3/0)
8x150 (300) 10x150 (300)
600 V, 2500 A
600 V,
1500 A
