Mechanical Installation

4.2 Requirements

This section describes the minimum recommended
requirements for mechanical installation. For UL and CE
requirements, see chapter 5.2 Electrical Requirements for
Certifications and Approvals.

4.2.1 Environmental

4 4
Refer to for information on required operating
temperature, humidity, and other environmental
conditions.
4.2.2 Cabinet
The kit consists of either 2 or 4 drive modules, depending
on the power rating. The cabinets have to meet the
following minimum requirements:
Width [mm (in)]
Depth [mm (in)]
Height [mm (in)]
Weight capacity
[kg (lb)]
Ventilation openings
Table 4.1 Cabinet Requirements
1) Required if Danfoss busbar or cooling kits are used.
NOTICE
EXTERNAL 230 V SUPPLY
An external 230 V supply is required for the SMPS
(switch mode power supply). Danfoss recommends using
a 6 A, 10 A, or 16 A slow-blow fuse when installing the
external supply.
14
®
VLT Parallel Drive Modules
2-drive: 800 (31.5), 4-drive: 1600 (63)
600 (23.6)
1)
2000 (78.7)
2-drive: 450 (992), 4-drive: 910 (2006)
See chapter 4.2.5 Cooling and Airflow
Requirements.
Danfoss A/S © 08/2017 All rights reserved.
4.2.3 Busbars
If the Danfoss busbar kit is not used, see Table 4.2 for the
cross-section measurements that are required when
creating customized busbars. For terminal dimensions, refer
to chapter 7.8.2 Terminal Dimensions and chapter 7.8.3 DC
Bus Dimensions.
Description Width [mm (in)]
AC motor 143.6 (5.7)
AC mains 143.6 (5.7)
DC bus 76.2 (3.0)
Table 4.2 Cross-section Measurements for Customized Busbars
NOTICE
Align busbars vertically to provide maximum airflow.
4.2.4 Thermal Considerations
For heat dissipation values, refer to chapter 7.1 Power-
dependent Specifications. The following heat sources must
be considered when determining cooling requirements:
•
Ambient temperature outside enclosure.
•
Filters (for example, sine-wave and RF).
•
Fuses.
•
Control components.
For required cooling air, refer to chapter 4.2.5 Cooling and
Airflow Requirements.
Thickness [mm (in)]
6.4 (0.25)
6.4 (0.25)
12.7 (0.50)
