Appendix
8.3.10 Connections in a 12-Pulse 2-Drive Module System
1
2
3
4
1 DC fuses
2 Drive module
3 Motor output bus bars connecting both drive
modules
4 Connection to mains input
Illustration 8.10 Connections in a 12-Pulse 2-Drive Module System
MG37K302
Installation Guide
R/ S/ T/ U/ V/ W/ R R
91 92 93 96 97 98 + -
5
6
7
8
Danfoss A/S © 08/2017 All rights reserved.
R/ S/ T/ U/ V/ W/ R R
91 92 93 96 97 98 + -
DC-link bus bars connecting both drive modules
DC terminals
Connection to brake
Connection to motor output
5
6
8 8
7
8
