7.8 Kit Dimensions

7.8.1 Exterior Dimensions
Illustration 7.2 shows the dimensions of the drive module related to its installation.
7 7
Illustration 7.2 VLT
Description
Drive module
Table 7.15 Drive Module Weight and Dimensions
64
346
(13.6)
280
(11.0)
95
(3.7)
107
(4.2)
213
(8.4)
320
(12.6)
271
(10.7)
®
Parallel Drive Modules Installation Dimensions
Module weight [kg (lb)]
125 (275)
Danfoss A/S © 08/2017 All rights reserved.
®
VLT Parallel Drive Modules
376
(14.8)
Length x width x depth [mm (in)]
1121.7 x 346.2 x 375 (44.2 x 13.6 x 14.8)
MG37K302
