Specifications

7.2 Mains Supply to Drive Module

Mains supply 1)
Supply terminals
Supply voltage 2)
Supply frequency
Maximum temporary imbalance between mains phases
True power factor (λ)
Displacement power factor (cos Φ)
Switching on input supply L1, L2, L3
Environment according to EN 60664-1
1) The unit is suitable for use on a circuit capable of delivering not more than 85000 RMS symmetrical Amperes, 480/600 V.
2) Mains voltage low/mains voltage drop-out:
During low mains voltage, the drive module continues until the DC-link voltage drops below the minimum stop level, which
corresponds typically to 15% below the lowest rated supply voltage. Power-up and full torque cannot be expected at mains
voltage lower than 10% below the lowest rated supply voltage. The drive module trips for a detected mains drop-out.

7.3 Motor Output and Motor Data

Motor output
Motor terminals
Output voltage
Output frequency
Switching on output
Ramp times
Torque characteristics
Overload torque (constant torque)
Starting torque
Overload torque (variable torque)
Starting torque (variable torque)
1) Percentage relates to the nominal torque.
Efficiency
Efficiency
1) Efficiency measured at nominal current. For energy efficiency class, see . For part load losses, see www.danfoss.com/vltener-
gyefficiency.

7.4 12-Pulse Transformer Specifications

Connection
Phase shift between secondaries
Voltage difference between secondaries
Short circuit impedance of secondaries
Short circuit impedance difference between secondaries
Other

7.5 Ambient Conditions for Drive Modules

Environment
IP rating
Acoustic noise
Vibration test
Vibration and shock (IEC 60721-33-3)
Maximum relative humidity
MG37K302
Installation Guide
No grounding of the secondaries allowed. Static shield recommended
5–95% (IEC 721–3–3; Class 3K3 (non-condensing)) during operation
Danfoss A/S © 08/2017 All rights reserved.
380–480, 500 V 690 V, ±10%, 525–690 V ±10%
3.0% of rated supply voltage
≥0.98 nominal at rated load
(Approximately 1)
Maximum 1 time per 2 minutes
Overvoltage category III/pollution degree 2
0–100% of supply voltage
Maximum 150% for 60 s
Maximum 180% up to 0.5 s
Maximum 110% for s
Maximum 135% for s
Dy11 d0 or Dyn 11d0
<5% of short circuit impedance
84 dB (running at full load)
R/91, S/92, T/93
50/60 Hz ±5%
7
U/96, V/97, W/98
0–590 Hz
Unlimited
1–3600 s
1)
1)
1)
98% 1)
30°
<0.5%
>5%
IP00
1.0 g
Class 3M3
