Specifications
Power range
Drive modules
Rectifier configuration
High/normal load
Output current [A]
Continuous (at 550 V)
Intermittent (60 s overload) at 550 V
Continuous (at 575/690 V)
Intermittent (60 s overload) at 575/690 V
Input current [A]
Continuous (at 550 V)
Continuous (at 575 V)
Continuous (at 690 V)
Power losses [W]
Drive modules at 575 V
Drive modules at 690 V
AC bus bars at 575 V
DC bus bars during regeneration
2
Maximum cable size [mm (mcm)]
Mains
Motor
Brake
1)
Regeneration terminals
Maximum external mains fuses
Table 7.7 FC 202, 525–690 V AC Mains Supply (2-Drive System)
1) If Danfoss bus bar kit is used.
MG37K302
Installation Guide
N315
2
HO NO
303 360
455 396
290 344
435 378
299 355
286 339
296 352
3688 4401
3669 4352
538 540
88 88
2x120 (250)
2x120 (250)
