Electrical Installation
Number of drive FC 302 FC 102/
modules
2 N250
2 N315
2 N355
2 N400
2 N450
4 N500
4 N560
4 N630
4 N710
4 N800
Table 5.6 12-Pulse Drive Systems (380–500 V AC)
Any minimum 500 V UL-listed fuse can be used for the 380–500 V AC
drive systems.
Number of drive FC 302 FC 102/
modules
4 N630
4 N710
4 N800
4 N900
4 N1M0
Table 5.7 6-Pulse Drive Systems (525–690 V AC)
Number of drive FC 302 FC 102/
modules
2 N250
2 N315
2 N355
2 N400
2 N500
2 N560
4 N630
4 N710
4 N800
4 N900
4 N1M0
Table 5.8 12-Pulse Drive Systems (525–690 V AC)
Any minimum 700 V UL-listed fuse can be used for the 525–690 V AC
drive systems.
MG37K302
Installation Guide
Recommended fuse
FC 202 (maximum)
N315 630 A
N355 630 A
N400 630 A
N450 800 A
N500 800 A
N560 900 A
N630 900 A
N710 1600 A
N800 1600 A
N1M0 1600 A
Recommended fuse
FC 202 (maximum)
N710 1600 A
N800 2000 A
N900 2500 A
N1M0 2500 A
N1M2 2500 A
Recommended fuse
FC 202 (maximum)
N315 550 A
N355 630 A
N400 630 A
N500 630 A
N560 630 A
N630 900 A
N710 900 A
N800 900 A
N900 900 A
N1M0 1600 A
N1M2 1600 A
