Appendix
8.3 Block Diagrams
8.3.1 Connection of 12-Pulse Disconnector/Interlock
1
2
3
4
8 8
5
6
7
1 Drive module 1
2 Drive module 2
3 Supplementary fuses
4 Mains input bus bars
5 Brake fault
Illustration 8.1 Connection of 12-Pulse Disconnector/Interlock
68
®
VLT Parallel Drive Modules
6 Disconnector 1
7 Brake fault
8 Drive module 3
9 Drive module 4
10 Disconnector 2
Danfoss A/S © 08/2017 All rights reserved.
8
9
10
MG37K302
