6.1 Pre-start Check List

Before completing installation of the unit, inspect the entire installation as detailed in Table 6.1. Mark the check-list items
when they are completed.
Inspect for Description
•
Auxiliary equipment Look for auxiliary equipment, switches, disconnects, or input fuses/circuit breakers that reside on the input
power side of the drive system or on the output side to the motor. Ensure that they are ready for full-
speed operation.
•
Check function and installation of any sensors used for feedback to the drive system.
•
Remove any power factor correction caps on motor(s).
•
Adjust any power factor correction caps on the mains side and ensure that they are dampened.
•
Cable routing Ensure that motor wiring and control wiring are separated or shielded, or in 3 separate metallic conduits
for high-frequency interference isolation.
•
Control wiring Check for broken or damaged wires and loose connections.
•
Check that control wiring is isolated from power and motor wiring for noise immunity.
•
Check the voltage source of the signals, if necessary.
•
Using shielded cable or twisted pair is recommended. Ensure that the shield is terminated correctly.
•
Check that the DC-link fuse and microswitch fixtures are correct. Check the microswitch cabling and the
connectors in the top of the drive module.
•
Cooling clearance Check that there is 225 mm (9 in) of top clearance for adequate cooling.
•
Ambient conditions Check that requirements for ambient conditions are met.
•
Fusing and circuit Check for proper fusing or circuit breakers.
breakers
•
Check that all fuses are inserted firmly and are in operational condition, and that all circuit breakers are in
the open position.
•
Grounding Check for good ground connections that are tight and free of oxidation.
•
Grounding to conduit, or mounting the back panel to a metal surface, is not a suitable grounding.
•
Input and output Check for loose connections.
power wiring
•
Check that motor and mains are in separate conduit or separated shielded cables.
•
Check that the shields are properly grounded.
•
Check that the DC-link connections are properly made.
•
Panel interior Inspect that the unit interior is free of dirt, metal chips, moisture, and corrosion.
•
Check that the unit is mounted on an unpainted, metal surface.
•
Switches Ensure that all switch and disconnect settings are in the proper positions.
•
Vibration Check that the unit is mounted solidly, or that shock mounts are used, as necessary.
•
Check for an unusual amount of vibration.
Table 6.1 Installation Check List
