Specifications
Power range
Drive modules
Rectifier configuration
High/normal load
Output current [A]
Continuous (at 380–440 V)
Intermittent (60 s overload) at 400 V
Continuous (at 460/500 V)
Intermittent (60 s overload) at 460/500 V
Input current [A]
Continuous (at 400 V)
Continuous (at 460/500 V)
Power losses [W]
Drive modules at 400 V
Drive modules at 460 V
AC bus bars at 400 V
AC bus bars at 460 V
DC bus bars during regeneration
2
Maximum cable size [mm (mcm)]
Mains
Motor
Brake
1)
Regeneration terminals
Maximum external mains fuses
6-pulse configuration
12-pulse configuration
Table 7.11 FC 302, 380–500 V AC Mains Supply (4-Drive System)
1) If Danfoss bus bar kit is used.
MG37K302
Installation Guide
N500 N560
4 4
HO NO HO NO
880 990 990 1120
1320 1089 1485 1232
780 890 890 1050
1170 979 1335 1155
857 964 964 1090
759 867 867 1022
7713 8810 8918 10199
6641 7628 7855 9324
655 665 665 680
647 656 656 671
218 218 232 232
4x185 (350)
4x185 (350)
8x70 (2/0)
6x125 (250) 8x125 (250)
600 V, 1600 A 600 V, 2000 A
600 V, 900 A
