Ramp

(TV formats only)
Description:
Test:
Method:
The active video area goes from full black (+7.5 IRE)
at the left edge of the screen to full white (+100
IRE) at the right edge.
Video Gain Linearity
When viewed on a TV screen, the full range of grays
should be visible. There should be no color shifts
visible.
4-51
