Quantum Data 801GC, 801GF, 801GX Owner's And Programmer's Manual page 232

CSPP
Classification:
Command Syntax:
Limits:
Query Syntax:
Query Response:
Description:
Other Required Cmds:
Example:
6-106
Chapter 6: Programming
Composite Sync Pulse Polarity
Format parameter setting
CSPP <polarity>
<polarity>
0 = active-low (negative going pulse)
1 = active-high (positive going pulse)
CSPP?
<polarity>
The CSPP command establishes the logic sense of the digital
composite sync output. The CSPP? query returns the current
setting of CSPP.
In order to use digital composite sync, it must be gated on with
the CSPG command and selected with the SSST command. The
FMTU command instructs the generator to use the new setting.
The ALLU command updates hardware to the new setting and
redraws the test image.
C S P G 1 / / E n a b l e
/ / b u f f e r
C S P P 1 / / S e l e c t
S S S T 2 / / C h o o s e
/ / i n b u f f e r
F M T U / / U p d a t e h a r d w a r e
/ / b u f f e r c o n t e n t s
Model 801GC, 801GF & 801GX¥Rev. A
d i g c o m p s y n c i n
a c t i v e h i i n b u f f e r
d i g i t a l c o m p s y n c
t o c u r r e n t
t y p e
