GRIV
Classification:
Command Syntax:
Limits:
Query Syntax:
Description:
Other Required Cmds:
Example:
6-132
Chapter 6: Programming
draw a GRIll pattern of Vertical lines
Custom image primitive
GRIV <color> <number of pixels in line> < number of pixels
in space>
<color> = available colors
<number of pixels in line> = number of lines
< number of pixels in space> = number of lines
None
Draws equally spaced vertical lines that form a grill over the
entire active video area. The gaps are not touched and will
show any previously drawn primitives. The primitive uses three
(3) parameters. The first is the color of the lines. The second is
the thickness of the lines and the third is the thickness of the
space between the lines.
The FMTU command instructs the generator to use the new
setting. The ALLU command updates hardware to the new setting
and redraws the test image.
G R I V c y a n 1 6 1 6
/ / 1 6 - p i x e l
/ / s p a c e s
A L L U / / U p d a t e h a r d w a r e
/ / b u f f e r c o n t e n t s
Model 801GC, 801GF & 801GX¥Rev. A
/ / D r a w c y a n g r i l l
l i n e s a n d 1 6 - p i x e l
t o c u r r e n t
w i t h
