Quantum Data 801GC, 801GF, 801GX Owner's And Programmer's Manual page 218

ASSS
Classification:
Command Syntax:
Limits:
Query Syntax:
Query Response:
Description:
Other Required Cmds:
Example:
AVCM
Classification:
Command Syntax:
Limits:
Query Syntax:
Query Response:
Description:
Other Required Cmds:
Example:
6-92
Chapter 6: Programming
Analog Sync Signal Swing
Format parameter setting
ASSS <level>
<level> (floating point accepted)
min = 0.000 volts
max = 0.307 volts
ASSS?
<level>
The ASSS command sets the maximum peak-to-peak swing for
any composite sync that's added to any of the three analog
video channels. The actual peak-to-peak swing of the analog
sync signals at the output connectors equals the product of ASSS
multiplied by ASSC. The ASSS? query returns the current setting
of ASSS.
One or more ASSG modes must be set to ON and the SSST type
must be 4, 5, 6 or 7 to output analog sync. The FMTU command
instructs the generator to use the new setting. The ALLU
command updates hardware to the new setting and redraws
the test image.
A S S S 0 . 2 8 6 / / S e t
/ / i n b u f f e r
F M T U / / U p d a t e h a r d w a r e
/ / b u f f e r c o n t e n t s
Analog Video Calibration Method
Format parameter setting
AVCM <type>
<type>
0 = Interpolate
1 = Measure Interpolate
2 = Measure Set Absolute
3 = Test Levels
AVCM?
<type>
The AVCM command determines how the generator tests and
calibrates its analog video outputs. The AVCM? query returns
the current setting of AVCM.
A V C M 1 / / S e l e c t
/ / t y p e o f
Model 801GC, 801GF & 801GX¥Rev. A
s y n c s w i n g t o
t o c u r r e n t
M e a s u r e I n t e r p o l a t e
s e l f c a l
2 8 6 m V
