SNUM
Classification:
Command Syntax:
Limits:
Query Syntax:
Description:
Other Required Cmds:
Example:
draw sequence Step NUMber
Custom image primitive
SNUM <color> <x> <y>
<color> = available colors
<x> = positive integer number
<y> = positive integer number
None
Displays the sequence step number to an image when it's drawn
as part of a test sequence. The number, along with the word
Step, appears in a small box. Seq. Step uses three (3) parameters.
The first is the color used for the text and box border. The next
two parameters are the X and Y coordinates for the position of
the box.
The displaying of sequence step numbers must be enabled with
the DNUM command and the custom image must have been
loaded as part of a sequence in order for this primitive to be
drawn.
S N U M w h i t e 5 0 5 0
/ / i n b o x w i t h
/ / X = 5 0 , Y = 5 0
/ / D i s p l a y s e q .
t o p l e f t c o r n e r
n u m .
a t
6-165
