Quantum Data 801GC, 801GF, 801GX Owner's And Programmer's Manual page 262

HSIZ
Classification:
Command Syntax:
Limits:
Query Syntax:
Query Response:
Description:
Other Required Cmds:
Example:
6-136
Chapter 6: Programming
Horizontal SIZe
Format parameter setting
HSIZ <physical size> (context sensitive - see FMTB and
FMTE)
<physical size> = positive value
(floating point accepted)
HSIZ?
<physical size> (floating point returned)
The HSIZ command establishes the horizontal physical size of
the image on the display. Units expected (or returned) vary
according to the last mode set with USIZ command. The HSIZ
command is context sensitive and must appear between begin
and end commands: FMTB and FMTE. The HSIZ? query returns
the current setting of HSIZ.
Note – Make sure that the USIZ parameter is properly set before
using the HSIZ command. Changing the USIZ setting after
entering HSIZ will convert the size to match the new unit of
measure.
The units of measure must be properly set by USIZ before entering
HSIZ. The ALLU command updates hardware to the new setting
and redraws the test image, taking the new size into account.
F M T B / / B e g i n e d i t i n g
/ / m o r e f o r m a t
/ / . . .
U S I Z 1 / / S e l e c t
/ / m e a s u r e
H S I Z 1 0 . 4 / / S e t
/ / b u f f e r
V S I Z 7 . 8 / / S e t
A L L U / / T e s t t h e
/ / O n e o r m o r e
/ / c o m m a n d s
/ / . . .
F M T E / / E n d o f e d i t i n g
Model 801GC, 801GF & 801GX¥Rev. A
s e s s i o n O n e
e d i t i n g c o m m a n d s
i n c h e s a s u n i t
i n b u f f e r
w i d t h t o 1 0 . 4 i n
h e i g h t t o 7 . 8 i n
n e w s e t t i n g s
f o r m a t e d i t i n g
s e s s i o n
o r
o f
b u f f e r
