Quantum Data 801GC, 801GF, 801GX Owner's And Programmer's Manual page 298

VSIZ
Classification:
Command Syntax:
Limits:
Query Syntax:
Query Response:
Description:
Other Required Cmds:
Example:
6-172
Chapter 6: Programming
Vertical SIZe
Format parameter setting
VSIZ <physical size>
<physical size> = positive value (floating point accepted)
VSIZ?
<physical size>
The VSIZ command establishes the vertical physical size of the
image on the display. Units expected (or returned) vary according
to the last mode set with USIZ command. The VSIZ command
is context sensitive and must appear between begin and end
commands: FMTB and FMTE. The VSIZ? query returns the current
setting of VSIZ.
Note – Make sure that the USIZ parameter is properly set before
using the VSIZ command. Changing the USIZ setting after
entering VSIZ will convert the size to match the new unit of
measure.
The units of measure must be properly set by USIZ before entering
VSIZ. The ALLU command updates hardware to the new setting
and redraws the test image, taking the new size into account.
F M T B / / B e g i n e d i t i n g
/ / O n e o r m o r e
/ / c o m m a n d s
/ / . . .
U S I Z 1 / / S e l e c t
/ / m e a s u r e
H S I Z 1 0 . 4 / / S e t
/ / b u f f e r
V S I Z 7 . 8 / / S e t
A L L U / / T e s t t h e
/ / O n e o r m o r e
/ / c o m m a n d s
/ / . . .
F M T E / / E n d e d i t i n g
Model 801GC, 801GF & 801GX¥Rev. A
s e s s i o n
f o r m a t e d i t i n g
i n c h e s a s u n i t
i n b u f f e r
w i d t h t o 1 0 . 4 i n
h e i g h t t o 7 . 8 i n
n e w s e t t i n g s
f o r m a t e d i t i n g
s e s s i o n
o f
b u f f e r
